HSF-2.2F/10

Last updated on December 18, 2023

HSF-2.2F/10 is a one-piece, foam backed, induction heat seal that gives a clean peel bond to polyethylene (PE) & polypropylene (PP)
Resistant to microbial growth and staining
Premium appearance
Available with standard or custom print

Construction¹

12,7

Polyester

0.5

254,0

Polyolefin Foam

10.0

12,7

Aluminum Foil

0.5

50,8

Heat Seal

2.0

Properties

Characteristic	SI	US
Oxygen Transmission	Essentially zero	Essentially zero
Moisture Vapor Transmission	Essentially zero	Essentially zero
Thickness Tolerance	± 10%	± 10%
Available Widths	25,4 – 1016,0 mm	1.0 – 40.0 in
Width Tolerance	± 1,6 mm	± 0.0625 in

Product Attributes

Mechanically strong and stable
Excellent chemical resistance
Good compressibility
Coextruded, not laminated, no adhesive
Resists discoloration

Good machinability
Does not promote microbial growth
No absorption
Non-toxic and free of odors and taste
Cost efficient

Compliance

US Compliance	Compliant with the following US regulations
US FDA	21 CFR 177.1630 Polyethylene phthalate polymers 21 CFR 177.1520 Olefin polymers 21 CFR 177.1210 Closures with sealing gaskets for food containers
US Drug Master File (DMF)	14762
California Proposition 65	California Proposition 65 Labeling Requirements
CONEG	Limitations of Heavy Metals in Packaging per CONEG
Safety Data Sheet (SDS) Statement	Safety Data Sheets (SDS) are not required for articles as defined in 29 CFR 1910.1200, the OSHA Hazard Communication Standard (HazCom). This product is an article as defined by HazCom and is not considered to be, or to contain, a hazardous chemical based on evaluations made by our company.
EU Compliance	Compliant with the following EU regulations
Safety Data Sheet (SDS) Statement	EU 94/62/EC, Article 11 EU 10/2011: Meets the compositional requirements of Regulation (EU) 10/2011 on plastic materials and articles intended to come into contact with food This product qualifies as an “Article”, as defined in art. 3.3 of Regulation (EC) no 1907/2006. As an “Article”, there is no legal obligation to provide a safety data sheet (SDS). TekniPlex provides its customers with the appropriate safety information for its products.

Storage and Handling

Storage Conditions

It is recommended that this material be stored at 15 - 30◦ C (59- 86◦ F) and relative humidity between 30 – 75%
The material must be protected from direct sunlight and high atmospheric humidity during storage. Large fluctuations in ambient temperature and high atmospheric humidity may lead to moisture condensing inside the packaging

Handling

For optimum quality and material processing:

The material should be stored at room temperature in the range of 15 - 30◦ C (59 - 86◦ F) for at least 48 hours prior to
processing
It is recommended to use the material within 12 months of the date of manufacture

Manufacturing Region

This PDS applies to HSF-2.2F/10 manufactured and supplied from TekniPlex’s North American facilities

Please note that construction does not necessarily reflect all adhesive or resin bonding layers, if present.

The numbers presented in this product data sheet are typical values and are not intended to be specifications.
